- Size: 95 m3
- Place of Origin: SHANDONG
- Brand Name: LUFENG
- Model Number: ST5250TQZCZ
- Weight: 23580.000 kg
Specifications
Wrecker Model | ST5250TQZCZ | |
Chassis Model | ZZ1257M5847C | |
Outline Dimension(L × W × H) mm | 10575 × 2495 × 3640 | |
Wheelbase mm | 5800+1400 | |
No. of Tire | 10 | |
Specification of Tire | 12.00-20 | |
Approach Angle/Departure Angle | 15 ° /16 ° | |
Front Overhang/ Rear Overhang mm | 1560/1840 | |
Reorganize and O utfit Q uality kg | 23710 | |
Boom | Max. Lifting Mass kg | 20000 |
Extension Stroke mm | 3510 | |
Max. Lifting Height mm | 9500 | |
Max. Inclination Angle | 50 ° | |
Rotating Angle | 360 ° | |
Range of Inclination Angle | 50 ° | |
Under Lift | Max. Lifting Mass kg | 16000 |
Rating Lifting Mass kg | 7000 | |
Rating Lifting Mass fully Extended kg | 4600 | |
Max. Effective Length mm | 2980 | |
Extension Stroke mm | 1640 | |
Range of Inclination Angle | -9 °～ 93 ° | |
Folding Angle | 102 ° | |
Outriggers | Supporting Force KN | 4 × 147 |
Longitudinal Span between Front Outrigger and Rear Outrigger (mm) | 6300 | |
Transverse Span of Front Outriggers (mm) | 5110 | |
Transverse Span of Rear Outriggers mm | 4225 | |
Rating Towing Mass kg | 30000 | |
Rating Pulling Force of Winch KN | 2 × 100 | |
Length of Cable Rope m | 4 0 | |
Attention: The chassis with the similar specifications Type II is available to choose 。 | ||
Lifting Specifications
Range | (Kg) Rating Lifting Mass |
3.25 | 7000 |
3.5 | 6000 |
4.0 | 5200 |
4.5 | 4800 |
4.89 | 4600 |
Attention: 1.Range means the distance between the point of lifting and the center of rear axis
2. Lifting mass means the mass on the lifting point
